The Heritage Plan is a 3-bedroom, 2.5-bathroom, 1,845 square foot home thoughtfully designed for narrow urban infill lots. Inspired by timeless farmhouse architecture and updated with modern functionality, this home delivers the warmth and character homeowners love while maximizing every square foot of livable space.
A welcoming covered front porch creates an inviting street presence and establishes a strong connection to the neighborhood. Inside, the main level opens into a spacious living room, dining area, and kitchen arranged around an efficient open-concept layout. Large windows flood the interior with natural light while maintaining privacy and comfort on compact urban sites.
Unlike many homes of similar size, the Heritage Plan places the primary suite on the main floor. Tucked away from the main living spaces, the suite features a generous walk-in closet, private bath, and direct access to the rear portion of the home for a quiet retreat from daily activity. A dedicated study, laundry room, and powder bath provide flexibility for remote work, hobbies, and modern family life.
The second floor offers two additional bedrooms connected by an open-to-below loft space that enhances natural light and creates visual volume throughout the home. This arrangement provides excellent separation between the primary suite and secondary bedrooms, making the plan ideal for families, multigenerational living, or hosting guests.
The exterior combines classic board-and-batten siding, steep gabled roof forms, covered porches, and farmhouse detailing to create a timeless architectural expression that feels equally at home in established neighborhoods and new infill developments.
Designed specifically for narrow lots, The Heritage Plan performs exceptionally well on flat sites while maintaining generous outdoor living spaces, including both a covered front porch and rear deck. Whether built as a primary residence, move-up home, or infill development product, this plan delivers enduring curb appeal, practical functionality, and comfortable living in a highly efficient footprint.
What's Included in This Plan Set
-
Architectural drawings — Floor plans, elevations, building sections, and roof plan.
-
Structural drawings — Foundation plan, framing plans, and structural details.
-
Electrical layout — Schematic electrical plan for permitting reference.
-
Site plan template — A blank site plan diagram sized for the intended lot width — your surveyor or civil engineer fills in your specific lot data.
-
Energy compliance notes — General energy code compliance notes for most U.S. jurisdictions.
-
Format — Print-quality PDF, delivered immediately at checkout. Files are 24" × 36" sheet size, standard for print shops and permit submissions.
